SMARTSCOPE FLASH 300 MANUAL
Whereas previous quality inspections required manual report creation, the new systems use networked QC-CALC data collection and statistical process control (SPC) software to manage, analyse and report inspection data from both machines. It is equipped with a 12:1 zoom lens that automatically compensates for magnification changes reducing operator inspection times. In addition, the OGP SmartScope Flash CNC 200 with 3D CAD based ZONE3 is an automatic measurement system that uses high-resolution optics and touch probe capability to ensure accurate, reliable inspection of components. The company, which has provided CNC machining to support clients in critical industries throughout the pandemic, purchased and installed two new inspection units which have allowed the company’s quality team to increase productivity of inspection reporting and maintains dimensional control directly on the shopfloor.ĭesigned for high volume inspection of precision cylindrical parts, a Vicivision M306 Techno allows for the fast, accurate inspection of components up to 300mm in length, 60mm in diameter and 10kg in weight.
It takes the total amount invested in new machinery at the West Pitkerro Industrial Estate facility over the past four years to close to a million pounds. GA Engineering Sliding Head, part of integrated manufacturing specialist Pryme Group, installed state-of-the-art inspection equipment earlier this year at a cost of £100,000. While the instrument head moves in the X, Y and Z axes, the part being measured remains stationary.A Dundee-based engineering firm has signalled its resilience following the announcement of a six-figure investment to enhance its existing inspection capabilities. Its unique carbon fiber composite X-axis beam exhibits superior noise-dampening characteristics, while its light weight contributes to measurement speed. SmartScope® Flash™ 635 (635 x 635 x 200 mm) – Provides measurement speed and stability. This design assures rapid, smooth part translation and robust measurement performance. An extended Y-axis travel of 610 mm is optional and either 300 mm or 400 mm extended Z-axis travel is available. Parts move on a precision DC motor-driven Y-axis stage while the optics assembly travels in the X-axis across a stable bridge cross member. SmartScope® Flash™ 500 (Contact us for XYZ Stage Travel details) – Offers all the great Flash features and performance in a large, travel bridge-design system.
It also comes standard with a TTL coaxial illuminator and patented LED SmartRing™ light. A high-quality auto calibrating AccuCentric® 12:1 zoom lens provides excellent optical performance over its entire range. It contains a unique “elevating bridge” design and axial straightness and perpendicularity are built in to meet stringent volumetric specifications. Add optional through-the-lens (TTL) laser, touch probe or micro-probe to configure a highly capable multisensor system. With an expansive Z-axis of 250 mm (10 in.) to accommodate large parts, it combines state-of-the-art video and autofocus to deliver high productivity. SmartScope® Flash™ 302 (300 x 300 x 250 mm) – One of the most versatile benchtop systems OGP offers. It’s ideal for a wide variety of manufacturing industries including metalworking, plastics, biomedical, electronics, automotive, aerospace and more. Its heavy cast base and rigid steel column provide metrology integrity so accuracy can be maintained in real world environments. Like all Flash systems, it is equipped with OGP® Measure-X® metrology software and 12:1 AccuCentric® zoom optics. Its large 300 mm X travel makes it the system of choice for measuring critical dimensions of long parts on a benchtop machine. SmartScope® Flash™ 250 (300 x 150 x 200 mm) – A compact machine designed for easy access to the XY stage for maximum fixturing flexibility. SmartRing™ light is standard for the ultimate flexibility in surface illumination. The computer controlled LED array backlight tracks X-axis motion of the optics with no moving parts. It also has patented innovations that let users do more, faster.
Innovative design features of “elevating bridge” and an embedded computer mean the system takes up little space on a benchtop while providing an ample measuring range and extensive measurement capabilities. SmartScope® Flash™ 200 (200 x 200 x 150 mm) – The smallest member of the Flash family of systems is a full-featured automatic measurement system.
